This oven has been specifically designed for the annealing of gypsums in the production process of casting precious alloys.
The particular design, the special construction features and the tested work cycle make it an innovative and precise tool that offers the customer the possibility to achieve the objectives described below:
absolute homogeneity in the internal temperature, which determines a considerable improvement in the baking of the gypsum, with a maximum temperature of 850 ° C, on request up to 1000 ° C.
accuration in the insertion of the cylinders-molds, ease in the internal cleaning.
cooking process controlled by a touch panel, complete with:
- a) nr. 50 cooking programs
- b) cooking curves up to 20 steps.
- c) management of the loading and unloading positioning of cylinders and dies
- d) start with timer
- e) storing cooking curves
- f) export of cooking data
management of the automatic opening and closing of the fireplace during the cooking cycle _management of a resistance in the wax drainage pipe, which avoids the formation of plugs
Optional :air insertion management to increase combustion, excellent for wax processing _ management of a forced cooling to decrease the cooling time.
Technical Data
MODEL | CAPACITY | POWER | DIMENSION in Cm | WEIGHT | SUPPORT |
---|---|---|---|---|---|
Cylinders D= 100 mm | Kw | A B H C | Kg | type | |
BFD-460 | 11 cylinders | 7 | 113 x 119 x 183 74 | 330 | rotative |
BFD-560 | 20 cylinders | 10 | 127 x 126 x 183 87 | 530 | rotative |
BFD-650 | 30 cylinders | 12 | 141 x 146 x 189 111 | 720 | rotative |
BFD-750 | 38 cylinders | 15 | 153 x 146 x 189 111 | 760 | rotative |
BFD-16-ST | 16 cylinders | 10 | 101 x 119 x 183 74 | 290 | static |
BFD-20-ST | 20 cylinders | 12 | 115 x 126 x 183 87 | 480 | static |
BFD-30-ST | 30 cylinders | 15 | 141 x 146 x 189 111 | 690 | static |
BFD-50-ST | 50 cylinders | 20 | 141 x 146 x 189 111 | 710 | static |
- Description
- Ask a question
- Review
They are mainly used for full finishing treatments.
Roughing, grinding and polishing very small objects. These machines integrate the rotational speed of the main disc with the four containers rotating about their axis, but in the opposite direction of the main disc.
The combination of these movements, together with the distinctive shape of the [wear- and aging-resistant] polyurethane inner containers and the new "Swivel System", provides a clean appearance.
Specifications :
Technical Details | U.M. | ROLLFAST 2008 |
---|---|---|
Overall dimensions | mm | 900 x 850 x 1500h |
Tank capacity | Lt | 3, 5 |
Tanks | n. | 4 |
Motor power | w | 1500 |
Max motor speed | rpm | 1400 |
Reverse direction | min | every 15 |
Speed regulation | Yes | |
Power supply | Volt | 220 (50 hz) Single phase |
Weight | kg | 325 |
- Description
- Ask a question
- Review
Description:
It is a versatile machine used for all wet finishing processes - roughing, sanding and polishing on jewellery pieces, all ferrous alloys, especially stainless steel.
The machine uses a vibration effect that is transmitted to the polyurethane tank by a vibrator of adjustable mass. Therefore, the materials placed inside the tank receive three types of movement:
centrifugal, helical and vibrating. Their combined action, in combination with water and abrasives (with liquid compounds or pastes) allows a higher level of finish to be achieved.
Technical Details | Mod. | cD 5L | cD 15L | cD 30L | cD 60L |
Overall dimensions | mm | =450 - h=600 | =600 - h=950 | =800 - h=950 | =900 - h=950 |
Stand dimensions | mm | 350 x 350 x 1000 h | 350 x 350 x 1000 h | 350 x 350 x 1000 h | 350 x 350 x 1000 h |
Weight | Kg | 50 | 113 | 205 | 260 |
Vibration intensity | rpm | 3000 | 3000 | 1500 | 1500 |
Intensity regulation | Adjustable | Adjustable | Adjustable | Adjustable | |
Timer | hr | 99 | 99 | 99 | 99 |
Vibration support | Vibration Dampers | Vibration Dampers | Medium springs | Medium springs | |
Tank capacity | Lt | 5 | 16 | 33 | 60 |
Lid | Yes | Yes | Optional | Optional | |
Power supply | Volt | 220 (50/60 Hz) | 220 (50/60 Hz) | 220 (50/60 Hz) | 220 (50/60 Hz) |
Single Phase | Single Phase | Single Phase | Single Phase |
- Description
- Ask a question
- Review
The cD series "ETNA"line includes a variety of continuous casting furnaces with crucible capacities ranging from 10 to 140 kg. A graphical interface and display assist the user in his task. A tubular frame and movable panel secure access to the machine body for simple maintenance. The profile drive system is made of aluminum, is fully cooled, and is powered by a stepper motor coupled to a planetary gear; it should be integrated with the casting chamber.
All of this system is closed by an easily removable cover: entry to melting equipment (Ceramic jacket, chain bushings, thermocouples) is very quick, minimizing replacement time. The cooling socket has been enhanced in accordance with the equipment so that The cooling socket has been refined in tandem with the equipment to provide the best potential performance.
The machine's heart is a mid-frequency system designed and constructed entirely by the Technical Opdel. These furnaces are frequently used for special profiles requiring a large quantity of metal to be melted. It can use accessories such as shears or saws to trim profiles and trays to cool them. In some cases, an additional tilting head can directly fill the empty crucible with liquid metal to minimize production slowdown.
Description | |
Panel control | Membrane keyboard with LCD graphic display and thermal printer for printing working cycles data. |
Heating System | Electric induction with no audible frequency |
Pulling System | With gearmotor, frequency and step adjustable, towing wheels and guide rollers |
Gas protection | By inert Gas |
Cooling | Long cooling socket for the die and regulation through bronze cooling rings |
Optional | Charging tilting head, saw or shear with holders, scarps saver, short cooling socket with water tank for profile rapid cooling. |
Model | Power | Crucible Capacity | Profile Sizes | Overall Sizes | Temperature |
cD 10 | 15,0 Kw | 11,2kg Au 18kt 14,0Kg Au 24Kt 7,6Kg Ag 925 | n. 1 Wire ø 8÷40mm n. 4 Wire ø 8÷12mm Plate (60÷75)x(5÷10)mm Tube ø 14+40 sp/th>=2 | 1050x815xh1750mm 310 Kg | 1.250°C 1.400°C (opt) |
cD 15 | 20,0 Kw | 16,2kg Au 18kt 20,0Kg Au 24Kt 11,0Kg Ag 925 | n. 1 Wire ø 8÷40mm n. 5 Wire ø 8÷12mm Plate (60÷90)(15÷10)mm Tube ø 14+40 sp/th>=2 | 1050x815xh1750mm 360 Kg | 1.250°C 1.400°C (opt) |
cD 20 | 22,0 Kw | 20,6kg Au 18kt 25,6Kg Au 24Kt 14,0Kg Ag 925 | n. 1 Wire ø 8÷40mm n. 6 Wire ø 8÷12mm Plate (75÷100)(15÷10)mm Tube me 14+40 sp/th>=2 | 1050x1015xh1950mm 390 Kg | 1.250°C 1.400°C (opt) |
cD 30 | 24,0 Kw | 30,8kg Au 18kt 38,3Kg Au 24Kt 21,0Kg Ag 925 | n. 1 Wire ø 8÷40mm n. 7 Wire ø 8÷12mm Plate (75÷115)x(5÷10)mm Tube ø 14+40 sp/th>=2 | 1050x1015xh1950mm 400 Kg | 1.250°C 1.400°C (opt) |
cD 50 | 30,0 Kw | 51,4kg Au 18kt 64,0Kg Au 24Kt 34,8Kg Ag 925 | n. 1 Wire ø 8÷40mm n. 8 Wire ø 8÷12mm Plate (115÷125)(15÷10)mm Tube ø 14÷40 sp/th>=2 | 1050x1015xh1950mm 465 Kg | 1.250°C 1.400°C (opt) |
All models can have a special drawing optional for production of ø80tube.
Consumables required for this machine :
- Description
- Ask a question
- Review
The "Vulcano" series includes special machines that make metal shapes. These machines are designed to be easier to maintain and use.
There are two types of these machines: Vulcano 3000-5000 and Vulcano 7/12. The first type can be put on a bench and has a smaller space for melting metal. The second type is placed on the floor and can create larger shapes using a roll holder.
You can control the machine using a keypad with numbers on it. To get inside the machine, there's a frame and a moving panel that can be opened. This makes it simple to fix and clean the machine.
The machine uses a special motor to shape the metal. This motor is cooled down and works with the metal-shaping part of the machine. The machine is covered with a removable cover. This cover can be taken off easily to quickly reach the inside parts that need to be replaced or fixed.
There's a cooling system that helps the machine work better. The design of the machine also includes a way to protect it from gases. The most important part of the machine is the middle frequency system, which was created by the Technical Opdel Department.
The machine comes with a control panel that has buttons and a display. It heats up metal using electricity, and the way it pulls and shapes the metal can be adjusted. It also has a system to protect it from gases. The machine can be cooled down using water.
If you want extra features, you can get things like gas protection, support, a cabinet to hold things, and tools like a saw or a shear. If you choose the Vulcano 7/12 machine, you need to order a water tank to cool it down quickly.
The machine can work at a maximum temperature of 1400 degrees Celsius.
Description
Control Panel: There's a special keyboard with numbers.
Heating: It gets hot using electricity without making a noise.
Moving: The parts that move can be controlled to go fast or slow, and they have wheels and rollers to guide them.
Gas Protection: Gas is used to keep things safe inside.
Cooling: Special rings help cool the parts that shape the material.
Optional: You can add extra features like more gas protection, extra support, a cabinet for holding things, and tools like a saw or a cutting tool.
Water Tank: For one of the models, there's a tank for water that helps cool things down quickly.
Maximum Temperature: The hottest it can get is 1400 degrees Celsius.
Model |
Power |
Crucible Capacity |
Profile Sizes |
Overall Sizes |
Temperature |
cD 3 |
8,5 kw |
3,6 kg Au 18 kt 2,5 kg Ag 925 |
Filo ø min. 4 - max 25mm nr. 2 ø 6-8-10 - nr.4 ø 4 Piatto min. 10x5 - max 50x5 Tubo min. 12x1,5 - max 30x5 |
760x920x800h 160kg |
|
cD 5 |
8,5 kw |
5,3 kg Au 18 kt 3,6 kg Ag 925 |
Filo ø min. 4 - max 25mm nr. 2 ø 6-8-10 - nr.4 ø 4 Piatto min. 10x5 - max 50x5 Tubo min. 12x1,5 - max 30x5 |
760x920x800h 160kg |
|
cD 7 |
9,5 kw |
5,3Kg Au 18Kt 6,6kg Au 24kt 3,6Kg Ag 925 |
n. 1 Wire ø 6÷15mm n. 2 Wires ø6÷12mm Plate (45÷50)x(5÷10)mm Tube øe 12÷35 sp/th>=1,5 |
800x900xh1500mm 275 K |
1.250°C 1.400°C (opt) |
cD 12 |
12,5 kw |
10,2Kg Au 18Kt 12,7Kg Au 24kt 6,9kg Ag 925 |
n. 1 Wire ø 8÷25mm n. 2 Wires ø 8÷12mm Plate (45÷60x(5÷10mm) Tube øe 12÷35 sp/th>=1,5 |
800x900xh1500mm 280 Kg |
1.250°C 1.400°C (opt) |
- Description
- Ask a question
- Review
Elevate Your Herd Management: Introducing the Delmer Cow and Buffalo Leg Sensor for Smarter Farming
Introducing the amazing Delmer Cow/Buffalo Leg Sensor – your super helper for taking care of your herd. Imagine having something that makes looking after your animals easier. This cool sensor does five important jobs, all packed into one.
Know Your Animals: Remember every Cow/Buffalo without any trouble. Our sensor knows each Cow/Buffalo and helps you keep records. Taking care of each one becomes simple and easy.
Help with Baby Calves: Be there when mommy cows are having babies. The Delmer Cow/Buffalo Leg Sensor tells you when it's time. You can help the mommy Cow/Buffalo and her baby stay safe and healthy.
Keep Cows Happy: Make sure your cows feel great and stay healthy. The sensor can check if your cows are doing well. It helps them rest and stay relaxed.
Step into the Future: Delmer is bringing the farm of tomorrow to you. This Cow/Buffalo Leg Sensor uses super smart technology. It really knows what your cows need. Make your farm better, your animals happier, and your work easier with this amazing sensor. We want you to succeed, and our Delmer Cow/Buffalo Leg Sensor will help you do it!
- Description
- Ask a question
- Review
Mini Tag - Your New Friend for Taking Care of Animals!
We've got something super cool to share with you - our Mini Tag! It's like a little helper that makes looking after your animals even better. We put lots of brainpower into making this tiny tag really awesome.
Just the Right Size: Our Mini Tag might be small, but it's a big deal when it comes to keeping your animals safe. It's made to fit snugly on all sorts of animals, from bouncy goats to gentle sheep. Your furry friends will feel comfy while you can relax knowing they're safe and sound.
Crazy Good Tracking: Don't be fooled by its size, this Mini Tag is like a superhero with tracking powers! It can tell you exactly where your animals are, anytime you want. You can easily see where they're munching, moving, and hanging out. We made it easy for you to understand on your computer or phone.
Tougher than Tough: Our Mini Tag is made for adventures! It doesn't mind rain or shine - it's built to handle whatever nature throws at it. Tough materials keep it going strong even when things get rough.
Works for Everyone: Whether you've got a small farm or a big one, the Mini Tag is your buddy. It's not just for goats and sheep - it can track other animals too! From fields to pens, it's like magic for all your animal pals.
Easy to Use: Making the Mini Tag part of your animal crew is simple. It plays nicely with other tracking stuff you might have, so you don't have to change a thing.
Be the Animal Pro: With the Mini Tag, you become a smart animal expert. It helps you make the best choices for your animals. You'll know when they're hungry, when they're moving, and when they're super happy. It's like giving them a voice!
Step into the Future: Get ready for the coolest way to take care of your animals - with the Mini Tag! It might be small, but it's a superstar at keeping animals happy. Lots of happy folks are already using it, and now you can too. Start your animal adventure with the Mini Tag today!
- Description
- Ask a question
- Review
Non-deformable, long-lasting, high quality, and environmentally sustainable most suitable for walking areas, milking parlors, reception areas, corridors & small gardens.
They are non-deformable, long-lasting, high quality, and environmentally sustainable most suitable for walking areas, milking parlors, reception areas, corridors & small gardens. Most useful in the areas where cows walk and move around to reduce jerks and impacts on their knees and legs. The Delmer Rubber Mats are certified by Fokus Test 08-376 for abrasion and slipping.
Features
- Excellent Installing and anti-fatigue
- High grip in both wet and dry
- Easy to install and clean
- Four side interlock design
- Anti fungal and anti microbial
- Bottom holds steadily to the surface
TYPE | LENGTH | WIDTH | THICKNESS | WEIGHT |
---|---|---|---|---|
Delmer Alley Mat | 6` | 3'9" | 22mm | 42±2Kg |
Technical Specifications
- Hardness : 65±5 Shore A
- Tensile Strength : 4 Mpa
- Specific Gravity : 1.2±0.05
- Abration Loss : 0.4gm(max)
- Elongation at break: 150% (min)
- Length Tolerance : ±5mm
- Wide Tolerance : ±5mm
- Thickness Tolerance: +2/-1mm
- Description
- Ask a question
- Review
Our Delmer EVA Cow Comfort mattress comes in 25mm and 35mm thicknesses and measures 1.82 x 1.22m (6ft x 4ft).
Our mattresses are available as single mats or at unbeatable great discount prices available for large quantities.
Made from high-quality, dense and durable expanded EVA foam, our cow pads provide the ultimate in cow protection.
Thanks to the application of premium materials, they provide the perfect insulation and reduce bed costs.
Excellent insulation on the cold concrete and good heat dissipation in hot weather. EVA mats mimic the natural ground and increase resting comfort for cows, thereby increasing their performance.
The cobblestone finish helps prevent animals from slipping, reducing the risk of injury.
Durable, impact resistant, lightweight for easy handling, and has excellent low temperature and sound insulation qualities.
If you install the mat yourself, we can supply fixings and washers, and can also supply aluminum strips to separate the compartments.
Nationwide installation service available.
- Description
- Ask a question
- Review
Ideal for polishing micro-mechanical parts and for a mirror-like finish.
KEY CHARACTERISTICS:
• Reverse and forward direction (clockwise and counter-clockwise)
• Clearance adjustment with cup rotation for 0.035mm. adjustment.
• Maximum rotation speed 450 rpm, the highest in the industry.
• Programmable melting temperature (via touch screen)
• Long lasting steel ring instead of ceramic.
• The case of having to change the tank is very cost-effective compared to other machines
LCD MANUFACTURER:
• LCD screen for better viewing.
• Memory capacity for 25 treatment programs.
• Display date and time.
• It shows that the bin is not. and also highlight the cannon doing it. Displays the processing time required for each bin as well as the time taken.
• In the menu, PROCESSING TIME, NEXT TIMER, ERROR TIME and SLOW END TIME can be set as needed.
• With SLOW FINISHING TIME, the machine works at a slow speed during the final processing stage to achieve a smooth finish.
• Container usage time can also be displayed.
• Memory capacity for 25 treatment programs. Highlight the current bin and bin number.
• Display processing time and execution time.
BACK TO CONTROL PANEL LCD - LCD - PANEL:
• LCD screen for better viewing.
• Memory capacity for 25 treatment programs.
• Display date and time. It shows the empty bin and also highlights the current bin.
• Displays the processing time required for each bin as well as the time taken.
• In the menu, TREATMENT TIME, FEED TIME, ERROR TIME and SLOW END TIME can be set as needed.
• With SLOW FINISHING TIME, the machine operates at a slow speed during the final processing period, to achieve a smooth finish.
• Container usage time can also be displayed
Specifications :
Specification Type | GD 9 | GD 2 x 9 |
Total Capacity | 9L | 2*9L |
Maximal Workpiece | 20 mm(maximal) | 20 mm(maximal) |
Barrel Speed | 0-450rpm | 0-450rpm |
Voltage | 220V/50Hz | 220V/50Hz |
Power | 370W | 370W x 2 |
Motor Speed | 1340rpm | 1340rpm |
Rate of Deceleration | 1:4 | 1:4 |
Dimensions | 535 x 670 x 820 mm | 935 x 670 x 820 mm |
Weight | 70 kg | 100 kg |
Specification Type | GD 18 | GD 2 x 18 | GD 3 x 18 |
Total Capacity | 18L | 2*18L | 3*18L |
Maximal Workpiece | 25 mm (maximal) | 25 mm (maximal) | 25 mm (maximal) |
Barrel Speed | 0-450rpm | 0-450rpm | 0-450rpm |
Voltage | 220V/50Hz | 220V/50Hz | 220V/50Hz |
Power | 750W | 750W x 2 | 750W x 3 |
Motor Speed | 1380rpm | 1380rpm | 1380rpm |
Rate of Deceleration | 1:4 | 1:4 | 1:4 |
Dimensions | 730 x 850 x 1410 mm | 1150 x 850 x 1410 mm | 1850 x 850 x 1450 mm |
Weight | 70 kg | 125 kg | 125 kg |
Specification Type | GD 36 | GD 2 x 36 | GD 3 x 36 |
Total Capacity | 36L | 2*36L | 3*36L |
Maximal Workpiece | 30 mm (maximal) | 30 mm (maximal) | 30 mm (maximal) |
Barrel Speed | 0-400rpm | 0-400rpm | 0-400rpm |
Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ |
Power | 2200W | 2200Wx2 | 2200Wx3 |
Motor Speed | 1430rpm | 1430rpm | 1430rpm |
Rate of Deceleration | 1:4 | 1:4 | 1:4 |
Dimensions | 890 x 1095 x 1445 mm | 890 x 1095 x 1445 mm | |
Weight | 175 kg | 350 kg |
- Description
- Ask a question
- Review
VACUUM PUMP:
Engine Power (Hp) :0,75Hp
Rotating (rpm) :1450rpm
Voltage (V) :220V
Flow Rate (L/min) :200
Palette Type :Fiber
Palette Size (mm) : 70x43x4.9
TankCapacity (L) :18
MILKING GROUP:
Bucket Type : S/S
Bucket Volume : 2x30Lt.
Cluster Weight (gr) :2050Gr.
Milk Claw Capacity : 2x240cc
- Description
- Ask a question
- Review
The Automatic Melting Furnace was designed to be a safe and easy-to use electrical method for melting gold, silver and other non-ferrous metals for casting and ingot-pouring applications. It offers precise control of melting temperatures up to 1120°C (2028 °F) through its user friendly, easily programmable controller with LED display.It comes with special kanthal heating element which gives higher operating temperature range and longer life. The glass wool insulated lid holds in heat and keeps oxygen out for a cleaner melt.
MODEL | CAPACITY | POWER (W) | SIZE (MM) | WEIGHT (KG) |
1 | 1 kg | 850 | 250*250*400 | 8 |
2 | 2 kg | 1300 | 250*250*400 | 8 |
3 | 3 kg | 1700 | 250*250*400 | 8 |
Specification of Product:
Features
|
|
Brand name |
Delmer |
Color |
Black & grey |
Finish type |
Rectangular Shape with Bright Enamel finish |
Dimension |
250X250X400 mm (for all capacity) |
Body material |
MS & SS |
Weight |
8 Kg |
Country of origin |
India |
Materials that can be melted |
Gold, Silver, Brass, Al & Its alloy. |
Technical details:
Features |
|
Design type |
Italian |
Plug Type |
3 pin plug (5 amp.) |
Power supply |
(850,1300,1700) W, 230V AC, Single Phase |
Max. temperature |
1200°C |
Display type |
LED |
Sensor type |
K type |
Heating element |
Kanthal (FeCrAl) |
Insulation coil |
Glass wool |
Continuous operating time |
1-2 Hours |
Melting time |
15 -20 Minute. |
Product included
|
1electric furnace,1 Graphite crucible without jacket,1 power cable,1 hand gloves,1 safety glasses,Tong & Manual guide |
WHAT IS AN ELECTRIC FURNACE ?
An electric furnace is a device whcih generates heat due to the resistance offered to the passage of current that is passed through it.
The furnace provided by us is of indirect heating type, which implies there is no contact between the heating element ( we use high quality & long lasting kanthal heating element ) and the crucible.
HOW DOES IT WORK ?
When you put the power on of the furnace , the current passes through the kanthal coil and heat is generated due to ohmic resistance and the coil becomes red hot ; This heat is transferred to the crucible by radiation which melts the material that is inside the crucible.
BENEFITS YOU GET :
- [PRECISE TEMPERATURE CONTROLHighly] advance digital control system combined with K-Type thermocouple, monitors the real time chamber temperature and make sure it doesnot overheat or cooldown providing you with precise and convenient melting.
- [LONGER LASTING HEATING ELEMENT] High quality Kanthal coil which can withstand high temperature uptp 1450°C and higher heating cycle . this is your term partner.
- [ QUICK MELTING ] the furnace comes with an insulation lid which resists the heat from escaping and easily melts your metal without any contamination.
- [ PORTABLE ] This machine is very compact and weighs only 8kgs , providing you the freedom of moving it wherever you like.
- [ 6 IN 1 SET ] The package comes with heat resistance gloves ,safety glasses for your safety ; tong and high quality graphite crucible with collar for easy handling and minimal contamination of the melt.
- [ EASY TO OPERATE AND MAINTAIN ] The furnace is so designed , it is extremely easy to set the parameters and operate and requires minimal or no maintenance.
HOW TO OPERATE :
- Pick an appropriate and safe working space to operate the furnace. Make it certain that the area in which you are working is madeup of incombustible material that won't catch fire in the event of liquid metal spill.
- Make sure there is safe distance of atleast 24 inch between the furnace and any combustible material or item that maybe present in the immediate surrounding.
- Put the crucible into the furnace chamber and make sure the crucible is touching the thermocouple properly.
- Add the material to be melted into the crucible(add Flux if required).
- Close the lid properly.
- Plug in the furnace into the 220V AC power supply.
- Turn on the green coloured ON/OFF button on the furnace (Green coloured light should be lit).
- For setting the temperature, Press the square button on the temperature controller, keeping it pressed press the up /down button to adjust it according to your requirement and then release.
- When the metal is melt turn off the green button.
- Take out the crucible from the furnace with help of a tong.
( NOTE:- Always wear safety glasses, gloves and safety shoes for your safety )
Customer Reviews
- Description
- Ask a question
- Review
PRODUCT DETAILS:
MODEL |
CAPACITY |
READABILITY |
PAN SIZE (MM) |
SD 10 |
10KG |
0.50 gram |
250 X 200mm |
SD 20 |
20KG |
1.00 gram |
250 X 200mm |
SD 30 |
30KG |
1.00 gram |
250 X 200mm |
SPECIFICATIONS:
- High Quality Budget Scale ( Legendary Z2+ eWeighing True Digital Technology ).
- lightweight &portable and highly precise
- (Legendary Z2+ technology used)
- Non Rusting ABS Body
- With Piece Counting, Litter Mode.
- Government certified from legal metrology department
- With Battery Backup with 6 Month warranty
- With 1 Year Warranty.
- Description
- Ask a question
- Review
Platform Scale
Model |
Capacity (kg) |
Readability (g) |
Pan Size (mm) |
TD - 40 | 40 | 5 | SS 300 X 300 |
TD - 50 | 50 | 5 | SS 400 X 400 |
TD - 60 | 60 | 10 | SS 400 X 400 |
TD - 100 | 100 | 10 | SS 400 X 400 |
TD - 120 | 120 | 10 | SS 400 X 400 |
TD - 150 | 150 | 20 | SS 500 X 500 |
TD - 200 | 200 | 20 | SS 500 X 500 |
TD - 200 | 200 | 20 | SS 600 X 600 |
TD - 300 | 300 | 50 | SS 600 X 600 |
TD - 500 | 500 | 50 | SS 500 X 500 |
TD - 500 | 500 | 50 | SS 600 X 600 |
TD - 500 | 500 | 50 | SS 750 X 750 |
Specification
- With SS 304 PAN Fully Powder Coated Structure with Heavy Gauge.
- Display: LED 7 digit (7 Segment LED), TARE facility with zero function.
- Government certified from legal metrology department.
- With IP 67 Water Proof Indicator.
- With Piece Counting, Litter Mode.
- With SS Water Proof Indicator.
- With 1 Year Warranty.
- Description
- Ask a question
- Review
Specifications
Model | Specifications |
---|---|
TD - 50 kg |
|
TD - 150 kg |
|
D - 200 kg |
|
- Description
- Ask a question
- Review
TD - 150
Specifications:
- With SS 304 PAN Fully Powder Coated Structure with Heavy Gauge.
- With ABS Indicator.
- Display: LED 7 digit (7 Segment LED), TARE facility with zero function.
- Government certified from legal metro-logy department.
- Widely Used for Industries , Gyms , Floor Mills , Grocery Stores etc.
- With Piece Counting, Litter Mode.
- With 1 Year Warranty.
- Battery backup 2 days.
- Platform size : 400 x 400 mm.
- Capacity : 150kg.
- Readability : 10 gram
